Hampdon Industrial Premium range of type 44 LPG (Propane) Gas Cutting Tips Suit Double (2) seated and suitable for use with common cutting head attachment. Cutting attachment to suit can be found in our store under gas equipment. See our other listings for a full range of tips and gas equipment. We also make custom length hoses with quality fittings. At Hampdon we believe in selling superior, high quality products that conform to relevant Australian standards, which have less incidence of product failure.

Features:

10 Each
Tip type 44
Tip size 15
For use with Oxygen and LPG gas (Propane)
Cutting Thickness 20 – 40mm
Cutting speed (Average) <> 250 mm/Min
Gas Consumption (Fuel): <> 5.5 L/min
Gas Consumption (Oxy): <> 100 l/min
Recomended Operating Pressure (Fuel): 100 kPa
Recomended Operating Pressure (Oxy): 400 kPa
Cutting Thickness 40 – 80mm
Cutting speed (Average) <> 180 mm/Min
Gas Consumption (Fuel): <> 6 L/min
Gas Consumption (Oxy): <> 120 l/min
Recomended Operating Pressure (Fuel): 100 kPa
Recomended Operating Pressure (Oxy): 400 kPa
CIG Equivalent part # 206029
BOC Equivalent part # 15C-P
BOSSWELD Equivalent Part # 400042
UNIMIG Part # CNP4415

Acetylene Cutting Tip Sizes & part Number (SKU)

Size 16 - 1-6mm = 44-6
Size 8 - 6-12mm = 44-8
Size 12 - 12-20mm = 44-12
Size 15 - 20-80mm = 44-15
Size 20 - 75-125mm = 44-20
Size 24 - 125-200mm = 44-24
Size 32 - 200-300mm = 44-32

(44-15-10)
