Hampdon Industrial Premium range of type 44 LPG (Propane) Gas Cutting Tips Suit Double (2) seated and suitable for use with common cutting head attachment. Cutting attachment to suit can be found in our store under gas equipment. See our other listings for a full range of tips and gas equipment. We also make custom length hoses with quality fittings. At Hampdon we believe in selling superior, high quality products that conform to relevant Australian standards, which have less incidence of product failure.

Features:

10 Each
Tip type 44
Tip size 20
Cutting Thickness 75 – 125mm
For use with Oxygen and LPG gas (Propane)
Cutting speed (Average) <> 100 mm/Min
Gas Consumption (Fuel): <> 6.5 L/min
Gas Consumption (Oxy): <> 170 l/min
Recomended Operating Pressure (Fuel): 100 kPa
Recomended Operating Pressure (Oxy): 400 kPa
CIG Equivalent part # 206030
BOC Equivalent part # 20C-P
UNIMIG Part #: UFBT-20 / CNP4420
BOSSWELD Equivalent Part # 400043

Acetylene Cutting Tip Sizes & part Number (SKU)

Size 16 - 1-6mm = 44-6
Size 8 - 6-12mm = 44-8
Size 12 - 12-20mm = 44-12
Size 15 - 20-80mm = 44-15
Size 20 - 75-125mm = 44-20
Size 24 - 125-200mm = 44-24
Size 32 - 200-300mm = 44-32

(44-20-10)
